Template Classification | Name | Parameter |
System Parameters | System nominal capacity | 232.96kWh |
Allowable operating temperature range | Discharge: -20~55℃; Charge 0~55℃ | |
Fire protection system | Perfluorohexanone | |
Cooling method | Liquid Cooling | |
System cycle times | ≥6000 times | |
Inverter operation mode | Three-phase three-wire grid-connected operation | |
How it works | On-grid/off-grid operation | |
System efficiency | ≥85% | |
Rated charge/discharge rate | 0.5C | |
External Communications | Ethernet, wireless 4G | |
Relative humidity | RH≤95% | |
Altitude | ≤2000m | |
Protection level | IP54 | |
Cabinet size | W*D*H=1720*1400*2380 | |
Weight | 2800kg | |
AC side parameters | Rated Power | 100kW |
Maximum Power | 110kW | |
Maximum current | 159A | |
Rated grid voltage | 3W/N/PE,230/400Vac | |
Output voltage frequency | 50/60Hz | |
Power factor range | >0.99 | |
DC side parameters | Battery module capacity | 280Ah |
Battery module configuration | 46.592kWh/1P52S | |
Battery system configuration | 232.96kWh/1P260S | |
Battery system voltage range | 702-936V |
